EchoPanel® 12mm 2800mm x 1200mm

EchoPanel® 12mm is the original PET acoustic panel, renowned for its sleek decorative surface and market-leading sustainability credentials — independently certified as carbon neutral by Climate Active. Designed and manufactured by Woven Image, EchoPanel® offers outstanding acoustic performance, design flexibility, and long-term environmental benefits.

Crafted from 60–80% post-consumer recycled PET sourced from plastic bottles, EchoPanel® is a premium upcycled solution with a 10-year life expectancy. At end-of-life, it is 100% recyclable, supporting circular design initiatives. Recognised globally, it holds multiple environmental certifications aligned with WELL™, LEED®, GreenStar®, and BREEAM® building standards.

EchoPanel® 12mm is pinnable, lightweight, printable, and easy to cut and install, making it ideal for a wide range of interior acoustic applications including walls, ceilings, and partitions. Its solid colour core ensures colour consistency throughout the panel, eliminating the need for edging or framing.

Key Features:

• Dimensions: 2800mm (±10mm) x 1200mm (±5mm) x 12mm (±7%)

• Composition: 100% PET (with 60–80% post-consumer recycled content)

• Sound Absorption Average (SAA):
  – Direct fix: 0.43
  – 20mm air gap: 0.61
  – 50mm air gap: 0.75

• Noise Reduction Coefficient (NRC):
  – Direct fix: 0.45
  – 20mm air gap: 0.60
  – 50mm air gap: 0.75

Environmental Certifications:

• Independently carbon neutral (Climate Active)

• Supports compliance with WELL™, LEED®, GreenStar®, and BREEAM®

• Manufactured with low-VOC emissions and sustainable practice

Click to view: Installation Guide
